Cimarron® Comfort Height® two-piece elongated 1.28 gpf toilet with AquaPiston® flush technology, left-hand trip lever and tank cover locks


K-3609-T-0
$448.60 List Price
COLOR:


TECHNICAL INFORMATION


Dimensions:

L 28-3/4", H 30-3/4", W 17-5/8"

Cimarron® Comfort Height® two-piece elongated 1.28 gpf toilet with AquaPiston® flush technology, left-hand trip lever and tank cover locks

Installation:

Floor-mount

This WaterSense®-labeled high-efficiency toilet combines water conservation with the versatile style of the Cimarron collection. A 1.28-gallon flush provides significant water savings of up to 16,500 gallons per year, compared to a 3.5-gallon toilet, without sacrificing performance. This toilet features innovative AquaPiston technology, a patented flush engine that delivers a fast, powerful, and virtually plug-free flush. An elongated bowl, positioned at the height of a standard chair, offers comfort and ease of use.

  • Features
  • Two-piece toilet.
  • Elongated bowl offers added room and comfort.
  • Comfort Height® feature offers chair-height seating that makes sitting down and standing up easier for most adults.
  • 1.28 gallons per flush (gpf).
  • Standard left-hand Polished Chrome trip lever included.
  • Tank locks included.
  • Combination consists of the K-4309 bowl and the K-4421-T tank.
  • Coordinates with other products in the Cimarron collection.
  • Technology
  • Single-flush gravity uses the force of gravity and a precision-engineered tank, bowl, and trapway to create a strong siphon during flushing.
  • AquaPiston canister allows water to flow into the bowl from all sides (360 degrees), increasing the power and effectiveness of the flush.
  • Flush valve's 3: 2 ratio harnesses the natural force of gravity and optimizes flush performance.
  • Durable canister design has 90% less exposed seal material than a 3-inch flapper, for leak-free performance.
  • Light-touch canister flush requires a lower actuation force than a flapper.
  • Installation
  • Standard 12-inch rough-in.
  • DryLock™ System saves installation time and helps prevent water leakage.
  • Seat and supply line not included.
  • Water Conservation & Rebates
  • WaterSense® toilets meet strict EPA flushing guidelines, including using at least 20 percent less water than 1.6-gallon toilets.
  • Eligible for consumer rebates in some municipalities.

Learn more about this product.


RESOURCES

PARTS


Toilet Parts Interactive Diagram
Tank Cover Locks Interactive Diagram

TECHNICAL INFORMATION


Dimensions:

L 28-3/4", H 30-3/4", W 17-5/8"

Cimarron® Comfort Height® two-piece elongated 1.28 gpf toilet with AquaPiston® flush technology, left-hand trip lever and tank cover locks

Installation:

Floor-mount

Rough In/Spec Sheet
Installation and Care Guide without Service Parts

TEMPLATE & SYMBOL DOWNLOADS


2D CAD Files:

Plan

DXF | DWG |

Front

DXF | DWG |

Side

DXF | DWG |

3D CAD Files:

RFA | DXF | DWG |
